ASME B16.9 Reducer is one type of pipe fittings ranging from ½ inches to 48 inches in diameter. R.C. Metal Corporation is a leading supplier and manufacturer of the Carbon Steel Concentric Reducer and other types. There are various types of the reducers and they all reduce the diameter of the pipeline at the point of connection. The SS Eccentric Reducer reduces the diameter to align with one side of the pipe. The concentric reducers does this parallel to the axis of the pipe line. The BW Reducer dimensions vary according to the standard and types. Most applications need the diameter of the pipes to be reduced parallel to the axis so the concentric reducer pipe fittings are most common.
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : 1/2"NB TO 48"NB IN
Type : Seamless / ERW / Welded / Fabricated
Thickness : Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.
Form : Concentric Reducer, Pipe Reducer, Pipe Concentric Reducers, Fitting Concentric Reducers.
| Specifications | ASME B16.9 Reducer |
|---|---|
| Bending Radius | Radius=1 D, 2D, 3 D, 5D, 6D, 8 D, 10D |
| Size Range | Seamless ButtWeld Fitting: From 1/2″ - 10″ Welded ButtWeld Fitting: From 1/2″ - 48″ |
| Dimension | ASME/ ANSI B16.9 | ASME B16.28 | MSS-SP-43 | BS1560 | BS4504 | BS10 |
| Size Ranges | ½” NB to 24″ NB in Schedule 10s, 40s, 80s, 160s, XXS. |
| Types | Welded | Seamless | Fabricated |
| Thickness of Fitting | SCH10, SCH 20, SCH30, STD SCH40, SCH80, SCH60, XS, SCH100, SCH 120, SCH140, SCH 160, XXS available with NACE MR 01-75 |
ASME B16.9 Concentric Reducer are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of Buttweld Reducer through a worldwide network of stock-keeping branches. These Concentric Pipe Reducer is use in various industries like :
Stainless Steel Buttweld Concentric Reducer uses in Oil and Gas Pipeline
Butt weld Concentric Reducers uses in Chemical Industry
Alloy Steel Concentric Reducer uses in Plumbing
Buttweld Concentric Pipe Reducer uses in Heating
Buttweld Concentric Reducer Fittings uses in Water Supply Systems
ANSI B16.9 Buttweld Concentric Reducer uses in Power Plant
Buttweld Concentric Reducer Fitting uses in Paper & Pulp Industry
Concentric Reducer uses in General Purpose Applications
Buttweld Concentric Reducer uses in Fabrication Industry
Concentric Reducer uses in Food Processing Industry
Buttweld Concentric Reducer uses in Structural Pipe
Conforms to ASME B16.9 & ASTM A234 WPB & etc.
All dimensions are in inches.
All weights are in pounds and approximated or estimated.
This size and thickness does not correspond to any pipe schedule number.
In accordance with B16.9. Special Fittings Paragraph 4.4.2
Concentric Reducers are specially designed fittings used in piping systems to connect pipe sections of different diameters, aligning the center axis of both pipes. These components are essential for managing the flow rate and pressure of the fluid within the pipes, ensuring a smooth transition between different pipe sizes. Made from various materials, including carbon steel, stainless steel, and alloy steel, Neo Impex’s concentric reducers are engineered to provide a durable and reliable solution for your piping needs.
Seamless Butt Weld Fittings conform to ASTM A/SA234 WPB through 24”
Weld Fitting Dimensions conform to ANSI B16.9, B16.11, B16.28 through 24”
Weld Fitting Dimensions larger than 24” conform to MSS-SP-48
Carbon content not to exceed .25% maximum
Manufacturing Facilities are ISO Certified
Mill Test Reports available with every order
